| 型 號 model |
週波數 Hz |
真空度 mbar |
排氣速度 m3/hr |
操作水量 m3/hr |
馬達出力 kw |
馬達轉速 rpm |
出入 管徑 |
進水 管徑 |
洩水 管徑 |
溢水 管徑 |
噪音值 dB |
重 量 kg |
| MEX 25 | 50/60 | 33 | 18/27 | 0.20/0.20 | 0.75/1.1 | 2850/3450 | 1" | 1/4" | 1/4" | - | 68 | 15/16 |
| MEX 50 | 50/60 | 33 | 35/44 | 0.50/0.50 | 1.5/2.2 | 2850/3450 | 1" | 1/4" | 1/4" | - | 69 | 23/25 |
| MEX 90 | 50/60 | 33 | 67/92 | 0.70/0.80 | 2.2/4.0 | 1450/1750 | DN 40 | 3/8" | 3/8" | 3/8" | 72 | 67/77 |
| MEX 125 | 50/60 | 33 | 92/108 | 0.78/0.80 | 3.0/4.0 | 1450/1750 | DN 40 | 3/8" | 3/8" | 3/8" | 72 | 71/79 |
| MEX 150 | 50/60 | 33 | 116/150 | 0.80/0.80 | 4.0/5.5 | 1450/1750 | DN 40 | 3/8" | 3/8" | 3/8" | 72 | 87/93 |
| MEX 250 | 50/60 | 33 | 184/201 | 1.20/1.26 | 5.5/7.5 | 1450/1750 | DN 65 | 1/2" | 3/8" | 1/2" | 72 | 114/123 |
| MEX 320 | 50/60 | 33 | 258/290 | 1.26/1.45 | 7.5/11.0 | 1450/1750 | DN 65 | 1/2" | 3/8" | 1/2" | 72 | 114/123 |
